NexBlue Edge 2 - BONUS Energy consumption meter

~~€787,95~~ €590,95 25% OFF

Gross price (incl. VAT) Shipping calculated at checkout.

Manufacturer: NexBlue
Max Power: 22 kW
Max Amps: 32A
Phase: 1&3
Colour: Black
Cable: No
MID: No

Color: Black

Black

Product variants

Quantity

5 years warranty from the manufacturer

Product description

Designed for home use, a 1/3-phase AC charger up to 32 A (installer-adjustable), with a maximum output of approx. 7.4 kW (1-phase, 230 V) / 22 kW (3-phase, 400 V) depending on the local grid. Approved for both indoor and outdoor installation, and fits any home electrical system. Connectivity: built-in Wi-Fi (2.4 GHz, 802.11 b/g/n). Safety: integrated residual current detection (Type A + 6 mA DC), disconnection via an external circuit breaker; IP55 rating. Compliance: CE, IEC 61851-1 CB.

Documents

Download Product Sheet

Installation guide

Download Installation Manual

Warranty

5-year manufacturer's warranty.

Color: Black

Black

NexBlue – smart charging for home and larger sites

EDGE 2: FOR HOME AND SMALLER SITES

Edge 2 supports up to 22 kW of power, single- and three-phase operation, Ethernet, Wi-Fi and 4G connectivity, and local and cloud-based load and phase management. It can be paired with a NexBlue Zen unit for dynamic control.

SOLAR POWER AND COST OPTIMIZATION

The NexBlue system can adjust charging to available grid capacity and surplus solar power. EcoPilot can schedule charging for more favorable periods based on available tariff information; utility support may vary by market.

DELTA: SCALABLE BUSINESS CHARGING

The Delta series is built for medium and larger sites. It supports Ethernet, Wi-Fi and 4G connectivity, local OCPP 1.6-J/2.0.1 communication, and local and cloud-based fuse and load management.
